Waukesha Votator 2 Overview

WAUKESHA VOTATOR II- SCRAPED SURFACE HEAT EXCHANGER

“Votator II Overview”



The Votator® II is the newest design of scraped surface heat exchangers. It is a combination of design features from the proven Votator family, Thermutator Heat Exchangers, and new innovations resulting in a rugged, economical, and hygienic heat exchanger that can be used for heating and cooling products of a wide range of viscosities, including extremely thick and sticky products that require the cam action of the eccentric design


• Can be mounted vertically or horizontally
• Sanitary appearance
• Minimum overall length
• USDA, CFIA, 3A and ASME design standard; CE-PED optional
• Tough 2” (50 mm) shaft spline
• Steam/water or gravity/pumped liquid refrigerant jacket configurations
• Concentric or eccentric shaft mounting
• Stainless steel exterior and stainless steel painted drive
• Open stainless steel mounting frame
• Boltless V-Lock heads for quick disassembly
• Splined mutator shaft removes in minutes
• Unique boltless blade mounting pins
• Gear motor drive – no couplings, belts or sheaves
• Heat transfer tube separate from media jacket. It has a reliable double O-Ring seal on each end and can be removed from the jacket in minutes without disturbing the media piping





*See SPX manual on Votator II located under the Manuals tab
